Available Sizes in Single Axle Models: 62″ x 8′ // 62″ x 10′ // 62″ x 12′ // 77″ x 10′ // 77″ x 12′ // 77″ x 14′ // 83″ x 10′ // 83″ x 12′ // 83″ x 14′
Available Sizes in Tandem Axle Models: 83″ x 14′ // 83″ x 16′ // 83″ x 18′
Specifications
*Hover over Spec for images where available
| GVWR | 2,990 on Single Axle Models
STANDARD | 7,000 on Tandem Axle Models
STANDARD | |
|---|---|---|---|
| Axles | 3,500# Spring Straight
STANDARD | 3,500# Electric Self-Adjusting Braked Axle – Includes Breakaway Kit and 7-Way Plug
OPTION | 5,200# Axles Standard on TA Models – Includes Electric Brakes
OPTION |
| A-Frame | 4″x 2″ Tube
STANDARD | ||
| Coupler | 2″ A-Frame Weld-On Coupler
STANDARD | 2-5/16″ Adjustable Coupler
OPTION | |
| Jack | 2K A-Frame Jack
STANDARD | ||
| Toolbox | N/A
STANDARD | Steel A-Frame Toolbox
OPTION | |
| Crossmembers | 2″ x 2″ x 3/16″ Angle
STANDARD | ||
| Decking | 2″ x 8″ Treated Pine Decking
STANDARD | ||
| Sides | 13″ Tall Tie Rail
STANDARD | ||
| Bed Height | 22″
STANDARD | ||
| Tie Downs | 4 – 3 Hole Tie Downs
STANDARD | Weld-on D-Rings or Tie Loops
OPTION | Stake Pockets IPO Tie Rail
OPTION |
| Tires | 15″ Radials (205/75R15)
STANDARD | 15″ Radial (225/75R15)
OPTION | |
| Rims | 15″ 5 Bolt White Modular
STANDARD | 15″ 5 Bolt Aluminum
OPTION | 15″ 5 Bolt Galvanized
OPTION |
| Spare Tire Carrier | Carrier On Front Wall
STANDARD | ||
| Rear Ramp | 4′ Fold Down Mesh – Folds Flat Onto Bed
*All Ramps Painted Black
STANDARD | Spring Assist (Single Spring)
OPTION | 4′ Bi-Fold Tailgate
OPTION |
| Side Ramp | N/A
STANDARD | 55″ ATV Side Mounted (n/a in 8′ or 10′ bed lengths)
OPTION | |
| Lights | LED Lights
STANDARD | ||
| Paint/Finish | PPG
Industrial Grade Poly Primer & Paint
STANDARD | Galvanized by AZZ Galvanizing
OPTION | |
| Color | Red, Orange, Gray, Silver, Blue, Yellow, Green, Dark Green
STANDARD | Galvanized by AZZ Galvanizing
OPTION | |
| Warranty | 5-Year Frame Warranty
STANDARD |
