21,000 – 25,990 Gross Vehicle Weight Rating
Available Sizes: 102″ x 24′ // 102″ x 28′ // 102″ x 32′ // 102″ x 36′
Features
- Square Torque Tube
- Self Adjusting Electric Brakes
- 16'' E-Range 10 Ply Tires (235/80R16)
- Rub Rail & Stake Pockets
- 102'' Bed Width
- 24'' Tilting Bed
- Hydraulically Locking Tilt
- Treated Wood Decking
- Tractions Strips
- Gooseneck Step (1 per side)
- No Exposed Wiring
- Cold Weather 7 Way Plug (-85°)
- LED Lights
- Dual Tail Lights
- Midship Turn Signals
- 12K Bolt on Spring Return Jack
- 30 Ton Pintle
- PPG Polyurethane Primer & Paint
Available Options
- Gooseneck
- 12K / 16K axles
- White Oak Decking
- Disc Brakes
- Hydraulic Power Tilt
- Dual Hydraulic Tongue Jacks
- Underbody Toolbox
- Contact your local dealer for more options
Specifications
- FBT-28
- FBT-32
- FBT-36
- FBT-40
- GVWR (lbs)
- FBT-28 22,000
- FBT-32 22,000
- FBT-36 22,000
- FBT-40 22,000
- GAWR (lbs/axle)
- FBT-28 10,000
- FBT-32 10,000
- FBT-36 10,000
- FBT-40 10,000
- Curb Weight
- FBT-28 6,460
- FBT-32 6,960
- FBT-36 7,460
- FBT-40 7,960
- Payload
- FBT-28 15,540
- FBT-32 15,040
- FBT-36 14,540
- FBT-40 14,040
