Tilt Bed Trailers

TBWB Series Tilt Bed Trailer

Heavy Duty Wide Body Tilt Bed Equipment Trailer

15,400 – 23,100 Gross Vehicle Weight Rating

Available Sizes: 102″ x 20′ // 102″ x 22′ // 102″ x 24′ // 102″ x 26′ // 102″ x 28′ // 102″ x 30′ // 102″ x 32′

Find a Dealerarrow Spec Sheet PDFarrow

Features

  • Self Adjusting Electric Brakes
  • 17.5'' H Range 16 Ply Tires (215/75R17.5)
  • 27'' Bed Height
  • Drive Over Fenders
  • 82'' Between Fenders
  • Grade 50 3'' Channel Crossmembers
  • 16'' Crossmember Spacing
  • 18' Tilting Bed
  • Hydraulically Locking Tilt
  • Treated Wood Decking
  • Rub Rail & Stake Pockets
  • No Exposed Wiring
  • Cold Weather 7 Way Plug (-85°)
  • LED Lights
  • 12k Spring Return Jack
  • 2-5/16'' Adjustable Coupler
  • PPG Polyurethane Primer & Paint
  • 5 Year Frame Warranty

Available Options

Midsota Wide Body Tilt Bed

Need the versatility of Full-Width Ramps and the reliability of a Sure-Trac Equipment? The Universal Ramp Implement was built to handle the job. Find out more in the Feature Video.




Color Options

Not exact color match. Contact your local dealer for color samples.

  • Standard Black
  • Optional Red
  • Optional Orange
  • Optional Gray
  • Optional Blue
  • Optional Yellow
  • Optional JD Green
  • Optional Safety Green
  • Optional Dark Green

Specifications

  • 18 + 4, 17.6k
  • 18 + 6, 17.6k
  • 18 + 8, 17.6k
  • 18 + 10, 17.6k
  • 18 + 12, 17.6k
  • 18 + 14, 17.6k
  • Model #
  • 18 + 4, 17.6k TBWB22-BP-176
  • 18 + 6, 17.6k TBWB24-BP-176
  • 18 + 8, 17.6k TBWB26-BP-176
  • 18 + 10, 17.6k TBWB28-BP-176
  • 18 + 12, 17.6k TBWB30-BP-176
  • 18 + 14, 17.6k TBWB32-BP-176
  • GVWR (lbs.)
  • 18 + 4, 17.6k 17,600
  • 18 + 6, 17.6k 17,600
  • 18 + 8, 17.6k 17,600
  • 18 + 10, 17.6k 17,600
  • 18 + 12, 17.6k 17,600
  • 18 + 14, 17.6k 17,600
  • GAWR (lbs./axle)
  • 18 + 4, 17.6k 8,000
  • 18 + 6, 17.6k 8,000
  • 18 + 8, 17.6k 8,000
  • 18 + 10, 17.6k 8,000
  • 18 + 12, 17.6k 8,000
  • 18 + 14, 17.6k 8,000
  • Curb Weight
  • 18 + 4, 17.6k 4,510
  • 18 + 6, 17.6k 4,760
  • 18 + 8, 17.6k 5,010
  • 18 + 10, 17.6k 5,160
  • 18 + 12, 17.6k 5,543
  • 18 + 14, 17.6k 5,460
